TROUBLE SHOOTING CODES

ERROR CODE DESCRIPTION SOLUTION
MROM  System ROM checksum error  Replace the main PWB (REP 5.1)
MRAM  RAM read/write check error. Replace the main PWB (Rep 5.1)
MAnn  Image memory address bus check error.
(nn) Indicates a bad bus number (00 to 08)
Replace the Main PWB (Rep 5.1)
MDnn Image memory read/write check error. (nn) indicates a bad segment number. MD)) through MD03, replace the main PWB (Rep 5.1)( MD04 and above, go to Rap 61
LB10 Memory Error. Replace the driver PWB (Rep 5.5)
LB11  Laser error. Replace Laser Unit
LB12  Fuser error.  Replace Fuser
LB13 A fan error.  -7041 W/O Tag 42- Go to     RAP 24.
-7042 & 7041 W/Tag 42- Go to RAP 63.
LB14 High voltage error.  Go to RAP 14.
LB15 Internal data error. Replace the following items in the order listed:
LB16  A command error. -Main PWB (REP 5.1)
LB17  Illegal command error.  -Driver PWB (Rep 5.5)
LB18 A setting error. -Setup PWB (REP 5.6)
LBnn  All other unlisted LB codes
LB19  Processor status error.  Go to RAP 19

NOTE: When these errors are encountered, switch off the power and wait 1 minute. Switch on the power. If the problem persists, follow the procedures given above. These error codes are shown in the display only.

      RETURN TO WORLD OF FAX MAIN PAGE

Click Here for Complete Parts Listing for this Model

ERROR CODE DESCRIPTION SOLUTION
001 Operation was stopped by opening the cover.  Close the cover & check the scanner and top cover interlock switches for marginal or intermittent operation.
If the problem repeats, go to RAP 26.
002 Document jammed or was too long. .
Remove jam and check for proper operation by performing a scanner drive test (05), ADF test method.
If the problem continues, go to RAP 40
003  Out of recording paper or jammed and memory was full.
Load paper, remove jam and check for proper operation by performing a printer test (00). If the problem repeat, go to RAP 31.
005 Modem hardware or timing error.  A mechanical error. Perform System Checks.
006 Hardware or timing error.  A mechanical error. Perform System Checks.
008 T1 time-out error. The two machines were trying to identify each other for greater than 35 seconds or busy tone was detected.  Procedures (off-line) do not indicate any problems, go to RAP 54.
009 Final attempt to redial was not successful. . Check the remote machine. Test the dialing functions
010 T1 timer (35 seconds) timed out while waiting for a response from the transmitter.  A receive error. If the System Checks procedures (off-line and on-line) do not indicate any problems, go
to RAP 54.
014 An error occurred in the laser printer or the scanner.  A mechanical error. Perform System Checks.
015 Drum & Drum counter should be replaced or toner is empty.  Check drum counter for proper installation or add toner.
100 A polling request (NSC/CIG/DTC) was initiated and the called machine did not respond within 35 seconds.
(T1) .
A polling error. If the System Checks procedures (off-line and on-line) do not indicate any problems, go to RAP 54.
101 A disconnect signal (DCN) was received from the called machine while waiting for it to identify all
capabilities (NSF/CSI/DIS).
A transmit error. If the System Checks procedures (off-line and on-line) do not indicate any problems, go to RAP 54.
102 A disconnect signal (DCN) was received from the  transmitter after sending local capabilities identification (NSF/CSI/DIS). A receive error. If the System Checks procedures (off-line and on-line) do not indicate any problems, go  to RAP 54.

NOTE: These error codes are showing the display and printed in the Activity Report.
